SIM authentication provides a seamless and secure user experience
EAP-SIM/AKA/AKA’/5G-AKA
SIM authentication, also known as EAP-SIM, EAP-AKA, EAP-AKA’, and 5G-AKA, provides a seamless and secure user experience. Users are automatically connected to secure Wi-Fi networks—enabled by 802.1x—defined in their Wi-Fi connection profiles. A 3GPP AAA, such as the Enea AAA Server, integrates with the mobile core’s user identity databases (HLR/HSS/AUSF) to authenticate and authorize users.
Furthermore, SIM authentication is used to derive keys for establishing IPsec tunnels to the mobile core for Wi-Fi Calling, as well as for generating cryptographic keys to secure the Wi-Fi network with encryption (WPA2/WPA3).
This approach effectively dispels the myth that Wi-Fi is inherently insecure. When employing EAP-based authentication, the Wi-Fi network is always secured with traffic encrypted over the air, providing a high level of security.
Additionally, EAP-based authentication is a foundational technology for Passpoint (Hotspot 2.0), enabling seamless and secure Wi-Fi roaming experiences, such as with the global network of OpenRoaming hotspots.
the why & how of
Download our white papers now.
Why? : An overview of the business benefits for mobile network operators (MNOs).
How?: A deep technical dive into successfully deploying a Wi-Fi offloading solution.
A key element of a successful indoor coverage strategy that leverages mobile data offloading is providing users with a seamless and secure Wi-Fi experience. SIM-based authentication is a powerful tool to achieve this, allowing cellular devices to use the credentials stored in the SIM card or eSIM to authenticate on a secure Wi-Fi network (802.1x). This enables users to automatically and securely connect to Wi-Fi networks without manual intervention.
Our SIM Authentication server, an integrated module within Enea AAA Server, performs EAP-SIM, EAP-AKA, EAP-AKA’, and 5G-AKA authentication optimized with the standard 3GPP AAA functionalities required for offloading scenarios. This enables secure SIM-based authentication for any Wi-Fi network—whether operator-controlled or operated by third parties. Additionally, Enea’s mobile offloading solution supports various alternative authentication methods for devices that lack SIM cards or do not support EAP-SIM/AKA/AKA’.
Below, we summarize the key differences between these EAP methods for SIM authentication.
| Consideration | EAP-SIM | EAP-AKA | EAP-AKA’ | 5G-AKA |
|---|---|---|---|---|
| Network Generation | 2G/3G | 3G/4G | 4G/5G | For 5G SA architecture. (Note that EAP-AKA′ will be used for a long time.) |
| Use Case | Wi-Fi authentication. | Wi-Fi authentication. | Wi-Fi authentication. | Cellular and Wi-Fi authentication. |
| Key Management | K_i (shared with USIM). | The key is derived from the SIM. | The key is derived from the SIM and will be further enhanced with Perfect Forward Secrecy (PFS)1. | The key is derived from the home network. |
| Security Features | Weak encryption. | Advanced security. | Further improved key management and security features. | Enhanced user equipment identity protection, no clear text identifiers2 enforced by SUCI in 5G. |
| Authentication Type | Challenge-response. | Challenge-response. | Challenge-response. | Challenge-response. |
| Key Derivation | Based on GSM algorithms. | Based on 3G/4G algorithms. | Improved key derivation (SHA-256). | Enhanced key separation. |
| Identity Protection | Limited. | Improved with protection against active attacks. | Further improved with stronger encryption. | Strong protection (SUCI) |
| Mutual Authentication3 | Yes | Yes | Yes | Yes |
The most common EAP method for Wi-Fi offloading today is EAP-AKA, closely followed by EAP-AKA′. For obvious reasons, EAP-SIM is mostly used in legacy deployments, and it will take time before we see widespread adoption of 5G-AKA.
One of the key advantages of using SIM/eSIM-based authentication methods (such as EAP-SIM, EAP-AKA, EAP-AKA’, or 5G-AKA) is that both the authentication process and data exchange are on par with the security levels of the cellular network.
In this section, we explore how the integrated Enea 3GPP AAA within the Enea Aptilo Service Management Platform (SMP)—available as both software and a cloud-based service on AWS—provides significant value for your mobile data offloading strategy.
For detailed technical insights, refer to the “SIM Authentication — How does it work?“ section.
In the “SIM Authentication – The 3GPP Way” section, we will outline all the 3GPP-specified scenarios for SIM authentication. However, it’s important to note that approximately 90% of our customers perform local traffic break-out, as illustrated in the diagram above.
The primary reason for backhauling traffic is to maintain a single point for managing policy and charging. However, this approach does not offload the mobile core. Offloading the RAN alone offers limited benefits if similar control can be achieved locally at the edge by integrating with the mobile core for policy and charging. This approach allows for improved traffic management and rapid policy enforcement, including Wi-Fi-specific policies, while maintaining the security advantages of SIM-based authentication.
Delivered as a module on the Enea Aptilo SMP, the SIM Authentication server seamlessly integrates with the mobile core to ensure a secure, seamless and consistent user experience during device authentication. Whether deployed as Enea Aptilo SMP (software) or SMP-S (AWS cloud service), the platform supports seamless Wi-Fi offload, Carrier Wi-Fi, B2B guest Wi-Fi and Wi-Fi Calling, all within the same scalable architecture. If you are only looking for a 3GPP AAA functionality for Wi-Fi Calling, we recommend using the Enea AAA Server for this purpose (The core of SMP).
Mobile operators (MNOs/MVNOs) can leverage their existing infrastructure for HLR, HSS, and AUSF by integrating a dedicated EAP-SIM/AKA/AKA’/5G-AKA authentication function.
The Enea Aptilo SMP SIM authentication server functionality (3GPP AAA) facilitates subscriber authentication using credentials stored in the SIM/eSIM. It enables SIM/USIM-based authentication for Wi-Fi users by interfacing with the existing HSS over the Diameter Wx interface (supporting 3GPP Release 7 and later). It can also connect with the HLR via the SS7/MAP D’/Gr’ interfaces (supporting 3GPP Release 6 and later). Although the 3GPP AAA server is not explicitly defined in the 5G SA standards, we believe it will re-emerge in real-world deployments, driven by pragmatic considerations. For more insights, see the section “Making It Work in The Real World Deployments.”
Furthermore, the Enea SIM authentication server solution can interact with core network elements such as the PCRF/PCF, DPI, and OSS/BSS systems like CRM to enable advanced policy management. For example, it can authenticate users seamlessly and then deliver tailored portal experiences or send SMS/emails based on location-specific or user-specific policies.
We also support static traffic steering policies, such as onboarding users with specific data plans, during certain times of day, or based on other criteria, specifically for access to the Wi-Fi network—particularly in locations where Wi-Fi coexists with 4G/5G. Additionally, our QoE-based selective offloading dynamically steers traffic in real-time, leveraging session-specific QoE KPIs from the mobile network to optimize overall user experience.
Our vendor-agnostic approach allows deployment regardless of the HLR/HSS/AUSF vendor or the system generation, enabling flexible integration into existing infrastructures.
When actively and automatically offloading cellular traffic, mobile operators need Wi-Fi services that are as reliable and scalable as their mobile networks.
This necessitates an architecture designed for high scalability and high availability. Our solution, built on the SMP core architecture, addresses this by offering linear scalability and geographic redundancy, ensuring both growth and resilience.
Additionally, it supports SNMP-based network management, allowing operators to seamlessly integrate it into their overall NOC operations and monitoring framework.
The Enea Aptilo SMP SIM Authentication server seamlessly connects to existing SS7 networks and offers an optional SS7 PCI-Express board for enhanced connectivity. For integration with next-generation IP networks, it supports SS7 over IP through built-in SIGTRAN capabilities. The IP-based SIGTRAN protocol and Diameter Wx utilize the server’s native high-capacity IP network adapter for robust physical connections.
To ensure smooth integration with the mobile core, the server supports a wide range of SS7 and SIGTRAN protocols, accommodating various national (ANSI, ITU, Chinese, Japanese) and hybrid variants. It provides authentication for both USIM- and SIM-based devices, enabling a seamless migration path from older to newer devices.
With a dedicated, purpose-built function for SIM-based authentication, service providers gain maximum flexibility regarding network topology. In environments with multiple HLR and HSS systems, we offer a central aggregation point for all Wi-Fi-based SIM authentication requests, allowing authentication across multiple HLR and HSS nodes from different vendors.
As discussed in the “Making It Work in The Real World Deployments” section, our solution can potentially extend to SIM authentication for 5G standalone (5G), even though the 3GPP AAA is no longer included in the 5G SA specifications. Utilizing the Enea Aptilo SMP’s Wi-Fi multi-vendor support for central aggregation, it is possible to integrate various Wi-Fi systems that use RADIUS signaling for the individual Wi-Fi networks.
Moreover, our solution allows for co-location with each HLR/HSS, and you can establish connectivity to the Wi-Fi AAA from each authentication node, optimizing network integration and efficiency.
Below, you will find how SIM authentication works for all non-3GPP access (Wi-Fi) scenarios specified by 3GPP. Please note that most (90%) of real-word deployments do not backhaul traffic to the mobile core. However, the SIM authentication process is identitical to the one for trusted non-3GPP access even if the traffic is handled locally by the Wi-Fi gateway.
The 3GPP AAA server, exemplified here by the Enea Aptilo SMP, plays a crucial role in SIM authentication for 3G, 4G, and 5G NSA networks. It securely manages the authentication process by integrating with the mobile core to verify the device’s credentials.
Untrusted non-3GPP Access is used for Wi-Fi networks that the mobile operator does not trust. This is why this is the access method of choice for Wi-Fi Calling, which must be available wherever there is a Wi-Fi network. Note that the 5G non-standalone (5G NSA) networks use the same mobile core (EPC) as 4G.
The user device is already assumed to be onboarded to the Wi-Fi network, for instance in a home, office or public hotspots. So, SIM authentication has nothing to do with security or login to the Wi-Fi network. Instead, SIM authentication is used to authenticate and authorize the user device to access the mobile core through an IPsec tunnel. The keys for setting up the IPsec tunnel are derived from the SIM authentication process.
In Wi-Fi networks, the 3GPP AAA serves a dual purpose for trusted non-3GPP access.
The user gets internet access through the local gateway, as shown in the picture below (the most common scenario). The traffic can also be backhauled to the mobile core using the 3GPP-specified trusted WAG/TWAG gateway functionality with an optional local traffic breakout.
Today (November 2024), relatively few 5G networks (50-60 networks) are utilizing the 5G standalone (5G SA) architecture, but this architecture will grow in importance over time. The authentication process for non-3GPP access, such as Wi-Fi, is more unified with the cellular authentication process, which introduces new technical challenges. One of these is how to be able to use Non-Access Stratum (NAS) signaling over Wi-Fi. The EAP-5G protocol has been introduced to encapsulate NAS messages to go over Wi-Fi through an IKV2 connection. So, EAP-5G is not an authentication protocol, which can be a bit confusing at first look.
The principles are the same as for untrusted Wi-Fi access towards the Evolved Packet Core (4G/5G NSA). The user is assumed to be already onboarded to the Wi-Fi network, and security is enforced by having an IPsec tunnel between the device and the mobile core.
The authentication process is very similar to the process for untrusted Wi-Fi access, with some important exceptions:
While the outlined flows above reflect 3GPP standards for SIM authentication, practical network implementations often favor pragmatic, hybrid approaches due to existing network design, equipment and investments.
In real-world deployments, the RADIUS protocol—widely used in Wi-Fi and various gateways—will likely continue to play a significant role alongside emerging 5G standards and protocols.
Historically, many 3GPP-specified interworking gateway functions for Wi-Fi (non-3GPP Access) have not seen widespread adoption for Wi-Fi offloading. For example, in 4G with the Evolved Packet Core (EPC), the tunnel-terminating ePDG gateway has primarily been used for Wi-Fi Calling rather than Wi-Fi offloading.
For Wi-Fi offloading in trusted Wi-Fi network environments, there has been limited demand for the WAG/TWAG to backhaul traffic to the EPC mobile core. In fact, the vast majority (around 90%) of Enea’s Wi-Fi offloading customer deployments opt to route traffic directly to the internet via a non-3GPP gateway, bypassing the mobile core. We foresee a similar trend in 5G SA, with a strong preference for local traffic breakout. Backhauling traffic through the mobile core only offloads the radio network (RAN), while local breakout delivers a more efficient solution by directly handling traffic at the edge.
In this context, the 3GPP AAA is expected to evolve and take the role of SIM-based authentication (control plane only) also in 5G SA, effectively offering a unified SIM authentication function across all generations of cellular networks. This evolution would give mobile operators a streamlined and pragmatic architecture, capable of handling SIM authentication seamlessly across both 4G and 5G core networks.
For Wi-Fi Calling utilizing untrusted Wi-Fi access in 5G SA, the N3IWF function will still be required. One potential scenario is the adaptation of the 3GPP AAA function as a “bridging function” within the authentication flow for Wi-Fi Calling. Mobile Network Operators (MNOs) often prefer leveraging established, proven technologies over quickly adopting new standards when practical alternatives exist. It’s important to note that the N3IWF is only a reference in the 3GPP standard and not a specific gateway product. An adaptive authentication server (3GPP AAA), like Enea’s Aptilo SMP, could potentially evolve to integrate with the 5G SA core for control plane authentication while the existing ePDG gateways manage the N3IWF roles within the traffic plane. The same scenario could also happen for trusted access, with the existing WAG/TWAG gateways taking over the TNGF/TWIF functions in the traffic plane. These scenarios would require cooperation between the 3GPP AAA and gateway vendors.
